SPEED R10

Pouch Lamination Machine

TOFO Speed R10

Pouch Lamination Machine
  • Heating roller internal heater
  • Full digital & LCD display
  • "Patent" air cooling system
  • Hot & cold laminating
  • Auto power-off system
  • Auto electricity safety system
  • Programmable memory key
  • Installed heat treatment motor gear
  • High speed working (max.4,000mm/min.) - TOFO SpeedR10
  • Auto ejector-TOFO SpeedR10
  • Powerful DC motor-TOFO SpeedR10
Enquiry Download Brochure
Specification

Maximum Width 330mm (13")
Maximum Speed 4,000mm/min.
Maximum Laminating Film 350mic. (14mil.)
Thickness of Mount 3mm
Heating System Heating Roller Internal Heater
Operation Temperature 0~160°C
Quantity of Roller 6 Heating Rollers + 2 Cold Rollers + 2 Ejector Rollers
Display LCD
Temperature Controller Yes
Speed Controller Yes
Reverse Switch Yes
Preheating Time 8 min.
Power Consumption 1,300Watts
Dimension 655 x 355 x 140mm
Box Dimension 727 x 420 x 210mm
Weight 27.4kgs(N)/29.4kgs(G)
Pallet Packing 24 units/pallet
